Nibco PCH206 BenchPressG™ Carbon Steel 45 DEG Elbow, 1/2 IN, Press
BenchPressG™ 45 DEG Elbow, Model PCH206, 1/2 IN, Press, Carbon Steel, 200 PSI, -20 - 250 DEG F, Industry Standards: ASME B31, CSA ANSI LC4/CSA 6.32, IAPMO Certified, UPC, IMC, NFPA 54, NFPA 58, NFPA 30, NFPA 30A, NFPA 31, 1.73 IN Center To End
Sub Brand | : | BenchPressG™ |
Item Name | : | 45 DEG Elbow |
Series/Model | : | Model PCH206 |
Nominal Size | : | 1/2 IN |
Connection Type | : | Press |
Material | : | Carbon Steel |
Maximum Pressure | : | 200 PSI |
Temperature Rating | : | -20 - 250 DEG F |
Industry Standards | : | ASME B31, CSA ANSI LC4/CSA 6.32, IAPMO Certified, UPC, IMC, NFPA 54, NFPA 58, NFPA 30, NFPA 30A, NFPA 31 |
Other Physical Dimension | : | 1.73 IN Center To End |
The NIBCO® BenchPressG® carbon steel 45 DEG elbow features a yellow HNBR o-ring and stainless steel gripper ring. Simply applying pressure from a pressing tool tightens the o-ring onto the pipe, ensuring a clean and secure seal in seconds with no threading required. The elbow has press connections. The fitting provides a method of changing the pipeline direction by 45 DEG.
Application: For heating fuel oil, compressed air, argon, liquid propane/butane gas, oxygen (non-medical), natural gas, diesel fuel, carbon dioxide, vacuum systems
