Stockham 15-SF-U Class 150 Cast Carbon Steel Bolted Cap Swing Check Valve, 2 IN, Flanged
Item Name | : | Swing Check Valve |
Type | : | Bolted Cap |
Series/Model | : | Model 15-SF-U |
Nominal Size | : | 2 IN |
Connection Type | : | Flanged |
Pressure Rating | : | 285 PSI |
Pressure Class | : | Class 150 |
Temperature Rating | : | -20 To 100 DEG F |
Body Material | : | Cast Carbon Steel |
Trim Material | : | API #8 |
Material Standard | : | Body: ASTM A216 Grade WCB |
Industry Standards | : | API 598, ASME B16.5, ASME B16.34, ASME B16.10 |
Width | : | 8 IN |
Lead Free | : | No |
Other Physical Dimension | : | 9 IN Inlet Center To Top Of Valve |
Swing check valves prevent reversal of flow through pipe lines. Most Stockham swing check valves can be installed in horizontal or vertical, upward flow, piping but we do not recommend that the valves be installed in vertical piping. They offer low resistance to flow and are particularly suited to low velocity service. The proper sizing of check valves is critical to performance.
