Trerice B852 300 Stainless Steel Rear Mount Bi-Metal Thermometer, 5 IN Dial, 2-1/2 IN L Stem, -40 To 160 DEG F
Bi-Metal Thermometer, Series/Model: Model B852, 5 IN Dial, Temperature Rating: -40 To 160 DEG F And -40 To 70 DEG C, Connection Type: 1/2 IN NPT, Connection Location: Rear, Bi-Metal Sensing Element, Graduations: 20 DEG F, 10 DEG C, Increments: 2 DEG F, 1 DEG C, Stem Size: 2-1/2 IN Length X 1/4 IN Diameter, Accuracy: Plus/Minus 1% Full Scale (ASME B40.3 Grade A), Outside Diameter: 5.21 IN, Dial Face: Aluminum, White Background With Black And Blue Graduations And Markings, 300 Stainless Steel Case, Stem Material: 300 Stainless Steel, Double Strength Glass Window, Black Pointer, Industry Standards: CRN Approved
Item Name | : | Bi-Metal Thermometer |
Series/Model | : | Model B852 |
Dial Size | : | 5 IN |
Temperature Rating | : | -40 To 160 DEG F And -40 To 70 DEG C |
Connection Type | : | 1/2 IN NPT |
Connection Location | : | Rear |
Sensing Element | : | Bi-Metal |
Graduations | : | 20 DEG F, 10 DEG C |
Increments | : | 2 DEG F, 1 DEG C |
Stem Size | : | 2-1/2 IN Length X 1/4 IN Diameter |
Accuracy | : | Plus/Minus 1% Full Scale (ASME B40.3 Grade A) |
Outside Diameter | : | 5.21 IN |
Dial Face | : | Aluminum, White Background With Black And Blue Graduations And Markings |
Case Material | : | 300 Stainless Steel |
Stem Material | : | 300 Stainless Steel |
Window Material | : | Double Strength Glass |
Pointer | : | Balanced, Black |
Industry Standards | : | CRN Approved |
The Trerice rear connect bimetal thermometer has been designed to meet the needs of standard industrial applications and installations. This instrument features a stainless steel, hermetically sealed case, providing weather tight protection.
